NO

                          Type

Specification

Remarks

   1.

      Raw material

Type

GI

Thickness

0.3-0.8

Yield strength

235Mpa TO 350Mpa

   2.

    Decoiler

Operation

Manual

Weight apacity

6tons

  3.

Main   body

Roller station

11/9stations

Diameter of shaft

75mm

Material of rollers

45# steel with chrome 0.05mm

Material of shaft

45# steel with chrome 0.05mm

Frame

350mm H-Beam

Chain

1inch

   4.

      Cutter

Operate

Automatic hydraulic type

Blade Material

CG12

Number

One hydraulic cutter

   5.

      Power

Pump motor for cutter

3kw

Main motor

3kw

Voltage

380V 50HZ

   6.

     Control

     system

Electric Box

PLC control system, Inverter,

encoder

Language

English

   9.

     Speed

             8-12m/min
